Xantrex Freedom XC PRO 2000 2000W Marine Inverter Charger 12vDC In 120vAC Out

Xantrex Freedom XC PRO Marine 2000

Model: 818-2015

Features:

• Extended Surge Rating: Surges to 2X continuous power for 5 seconds for motor loads
• True Sine Wave AC Power: For operation of sensitive and motor loads
• Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off
• Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis
• Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input
• Easily configurable settings to charge any lithium ion battery
• Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers
• Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V
• Battery Equalization: Maximizes flooded battery life
• Dead Battery Charging Down to 0 Vdc
• Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting

A true sine wave inverter with a built-in lithium-ion battery charger and transfer switch in a compact, lightweight footprint. Configure and monitor system performance via Bluetooth app available on the optional Bluetooth remote panel (# 808-0817-02). SEAMLESS INTEGRATION WITH MICRO-C NMEA 2000 CONNECTOR

The Freedom XC PRO Marine inverter/charger, supporting CANbus NMEA 2000 protocol, is the most versatile and flexi- ble AC power solution in the market today. It supports seamless integration with third party monitoring and control systems. It also features a 100 amp (2000W model) / 150 amp (3000W model) battery charger and offers all of the configurable features of the Freedom XC series inverter/charger in a compact, light weight package. It cranks out full output in invert or charge mode from -4 degrees F (-20 degrees C) – 104 degrees F (40 degrees C) for operation in all climate temperatures. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably.

Specifications

ELECTRICAL SPECS – INVERTER
AC Output Operating Voltage Options	120, 110, 108 Vac
Continuous Output Power	Continuous Power 2000 W @40 C True sine wave (TSW)
Continuous AC Output Current	16.7 A
Surge Power	4000 W (? 5 sec)
Frequency (Configurable)	60 (or 50) Hz
Peak Efficiency	91%
Full Load Efficiency	gretaer than or equal to 86%
DC Input Operating voltage range	10.1 – 18.0 VDC
DC Input Max Non-Operating Voltage	25.2 Vdc
DC Nominal Current at Full Load	192 Adc
ELECTRICAL SPECS – BATTERY CHARGER
Min Battery Voltage for Charging	0.0 Vdc
Max DC Output Voltage	18.0 Vdc (custom battery type)
Selectable DC Output Current	User Selectable: 5 – 100 A
Full Load Max AC Input Current	24 Arms
Max DC Charge Current (selectable down to 5A)	100A
Operating Input AC Pass-Through Voltage Range	85-140 Vac
Safe Non-Operating Input AC Voltage Range	Up to 240 Vac RMS
Power Factor at Full Charge Rate	> 98%
GENERAL SPECS
Operating Temperature Range	4 to 140 F (-20 to 60 C), with output derated above 104 F (40 degrees C)
Storage Temperature Range	-40 to 158 F (-40 to 70 C)
Operating Humidity Range	5 to 95% RH, non-condensing
Transfer Relay AC Current Rating	30 A surge, 24 A continous
DC Input/Output Nominal Voltage (inverting/ Charging)	12.0 Vdc
L x W x H (without flanges)	15.4(390 mm) x 10.8(275 mm) x 4.9(125 mm)
L x W x H (with flanges)	16.0(406 mm) x 12.0(305 mm) x 4.9(125 mm)

What’s in the Box:

• Freedom XC PRO 2000
• one set of plastic bushings for large DC cables
• one pre-installed DC ground enclosure lug
• two AC knockout hole plugs
